PlateMate

Dual force plate system designed for fast testing and accurate data. Measure up to 125 metrics across jumps, isometrics, balance and movement.

Key Specifications
SpecificationDetails
Sampling Frequency960 Hz
Maximum Load Capacity4,000 kg per plate (1,000 kg per load cell)
System RequirementsWindows or macOS PC. iPad supported with optional wireless module
Weight & Dimensions9.8 kg per plate · 50 × 35 × 8 cm
Measurement Accuracy0.15 N
Natural FrequencyApproximately 550–750 Hz
Warranty2 years
PlateMate Product Features
125+ Performance Metrics
Evaluate jumps, isometric strength, balance, and movement with 125+ measurable metrics, including RFD, Peak Power, RSI, and more, providing objective performance data.
Quick Plug & Play Setup
Start testing in as little as 10 seconds. Simply connect via USB for power and data, launch the software, and begin testing. An optional wireless module is also available.
High Precision & Built to Last
Delivering 0.15 N accuracy, a 960 Hz sampling frequency, and a maximum capacity of 4,000 kg per plate (1,000 kg per load cell), PlateMate offers dependable and durable performance.
API Connectivity
Use the open protocol and API access to export your measurement data and integrate it with external platforms for further analysis.
Independently Validated
PlateMate has been benchmarked against gold-standard AMTI force plates, validated using the MyJump app, and internally compared with Vald ForceDecks.
Product Description

Plate Mate is built for precise jump analysis and isometric strength testing, providing dependable force measurements during both dynamic and static assessments.

Comprehensive analysis: Track movement, balance, isometric performance, and all major jump variations, including countermovement jumps, squat jumps, drop jumps, and pogo jumps.

Easy setup and connectivity: Connect directly to Force Mate software via USB. An optional wireless module enables Bluetooth connectivity and iPad compatibility.

Plug & Play: USB-powered for simple operation, with wireless functionality available through the optional Bluetooth module. Calculate 125+ performance metrics, including jump height, flight time, RFD, RSI, and more. One-time purchase with no subscription or recurring fees. Full data ownership with API export support. Open, human-readable USB serial protocol. Externally validated against gold-standard force plates. Includes a two-year warranty.

Available in Blue or Grey: Each plate is anodized and hand-assembled in Denmark, so minor colour variations may occur between production batches. The software is available in Czech, German, English, Spanish, Finnish, French, Italian, Polish, Thai, Turkish, and Simplified & Traditional Chinese.
